 OPzV Tubular Gel Battery 2v Series

Product Description
1. SunLike OPzV Gel Range are maintenance free sealed valve
regulated lead acid rechargeable batteries offer their superior
performance and reliability.
2. SunLike state-of-the-art manufacturing facilities with wealthy
experience ensure safety,outstanding battery life and value.
Each cell is 100% factory tested.
3. SunLike OPzV Gel Range batteries can be used in float or
deep cycle service and have a Design life of 20 years at 20°C.
4. SunLike OPzV Gel batteries can be stored up to 2 years
at 20-25°C without  fresh charging.


Characteristics
1. Plate: Positive plate adopt tubular plate which can prevent active material falling,and adopts muti-component alloy frame. Have fine corrossion-
resisting performance and long cycle life. Negative plate adopts
special radiated structure.
2.Separator:PVC-SiO2 separator with big porosity and low resistance.
3. Electrolyte:Germany gas sillicon dioxide electrolyte in gel state in the
battery without flowing leakage and lamination can be avoided.
4. Safety valve: Adopt Germany technology,constant opening and closing,
accumulator expansion,damage and electrolyte dry up can be avoided.
5.Standard: Proof against deep discharge according to DIN 43539 T5.
6. Design life: 20 years at 20ºC ambient, 3-5 Years warranty at 20℃/68°F .
7. High Power Cycles: at least 1500 cycles under 100% D.O.D at 20℃/68°F


Application:
1. Medical Equipment
2. Telecommunications
3. UPS Cable Television
4. Railroad Utility Electric Utility
5. Photovoltaic System
6. Control Equipment
7. Alternative Energy System Security System

Construction:
Component ......Raw material
Safety valve .....EPDR
Positive ........Lead dioxide
Terminal ........Copper
Negative........Lead
Separator ......PVC-SiO2
Container........ABS
Electrolyte .....Sulfuric acid
Cover........ABS    Thixotropic Gel


Model Nominal Voltage (V) Capacity External Dimension   Weight
Length Width Height Total Height
mm mm mm mm kg
OPzV2-200 2 200 103 206 356 389 20
OPzV2-250 2 250 124 206 356 389 23.5
OPzV2-300 2 300 145 206 356 389 28
OPzV2-350 2 350 124 206 473 505 29.5
OPzV2-420 2 420 145 206 473 505 35
OPzV2-500 2 500 166 206 473 505 41
OPzV2-600 2 600 145 206 646 678 49
OPzV2-800 2 800 191 210 646 678 65
OPzV2-1000 2 1000 233 210 646 678 80
OPzV2-1200 2 1200 275 210 646 678 93
OPzV2-1500 2 1500 275 210 795 827 117
OPzV2-2000 2 2000 399 212 770 802 155
OPzV2-2500 2 2500 487 212 770 802 192
OPzV2-3000 2 3000 576 212 770 802 228
